Regular price
$965.00
Sale price
$406.34
Shipping calculated at checkout.
Quantity must be 1 or more

  • Carpanelli®
  • NEMA 56C Flange & 3 position Movable/Removable Feet
  • 2hp/1.5Kw Output Power
  • 4-pole 1700rpm 208V/60Hz
  • 4-pole 1730 rpm 230/460V/60Hz
  • 208V 8.2A Y-Y 3 phase AC
  • 230V 8.2A Y-Y 3 phase AC
  • 460V 4.1A Y 3 Phase AC
  • Power Factor 0.82 @208V/60Hz
  • Power Factor 0.75 230/460V/60hz.
  • IP55 - Ingress Protection Rating
  • Class F Insulation System
  • 2RS Sealed ABEC 5 Electric Motor Bearings
  • Service Class S1 (1.2 Service Factor 230 & 460V/60Hz)
  • NC 130ºC Thermostat Circuit in Windings.
  • UL CSA and CE Listed & Approved
  • TEFC - Totally Enclosed Fan Cooled
  • 9-lug terminal block for solid & clean terminations.
  • Reposition-able in 90º turns IP65 Terminal box.
  • Compact & Lightweight due to high strength die-cast aluminum alloy housing.
  • OPTIONAL - Self Braking, Programable Encoder, Force Ventilation Systems. Configure/Price/Order On-line.
  • Superior cooling to Iron or Inexpensive wrapped steel motors.
  • Made in USA from 100% Designed & Manufactured from Italian Components.
  • Standard Shipping 1-3 days ARO ≤5 pieces (5> inquire).
  • Expedited Production & Shipping Available (SAME DAY) inquire to sales@tvtamerica.com
