TVT America
TFP160La4
TFP160La4
Regular price
$2,698.23 USD
Regular price
$5,396.00 USD
Sale price
$2,698.23 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
MT TFP Series High Performance 3phase AC Brake motor | |||
IEC 160La 4pole 11Kw 400∆/690Y Volts/50hz, 480∆/820Y Volts 60Hz 1.2 Service factor | |||
Ingress Protection 5 Dust, 4 Solids, Class F Insulation, S1 Continuous Duty | |||
PTC Thermistor thermal protectors in stator windings. 3ph AC brake Standard 400∆/690Y Volts/50hz, 480∆/820Y Volts 60Hz 24Vdc & 103Vdc brakes optional. |
|||
Die-cast Aluminum Housing Polyester Epoxy Painted RAL 9006 White Aluminum for superior corrosion protection. | |||
Pressed Steel brake Cover Polyester Epoxy Painted RAL 5010 TVT Blue. | |||
Double Terminal Box, rotatable at 90º intervals, for convenient wiring and Protection IP56 | |||
UL/CSA/CE listed, ATEX Ex 2-22 3G/3D certified. | |||
"Made in Italy… Loved in America"® |
